Digital Printing Machine – Nozomi C18000

Fast job turns and rapid business growth in a single pass

Supercharge your corrugated, packaging, and merchandise display printing capabilities with single-pass LED digital inkjet technology from EFI™.

Press Release
Nozomi C18000 Video
null
Image Gallery
a-76
a-85
a-83
a-84
a-78
a-76
a-81
a-82
a-79
a-78
a-80
a-77
a-76
a-74
a-75
a-72
a-73
a-71
a-70
a-69
a-68
a-66
a-67
a-65
a-63
a-64
a-62
a-61
a-60
a-59
a-58
a-57
a-56
a-55
a-54
a-53
a-52
a-51
a-50
a-49
a-48
a-47
a-46
a-45
a-44
a-43
a-42
a-40
a-41
a-39
a-38
a-37
a-36
a-35
a-33
a-32
a-34
a-31
a-29
a-30
a-27
a-28
a-26
a-25
a-23
a-24
a-22
a-21
a-20
a-19
a-18
a-17
a-16
a-15
a-13
a-14
a-11
a-12
a-10
a-9
a-8
a-7
a-6
a-4
a-5
a-3
a-2
a-1
a-76 a-85 a-83 a-84 a-78 a-76 a-81 a-82 a-79 a-78 a-80 a-77 a-76 a-74 a-75 a-72 a-73 a-71 a-70 a-69 a-68 a-66 a-67 a-65 a-63 a-64 a-62 a-61 a-60 a-59 a-58 a-57 a-56 a-55 a-54 a-53 a-52 a-51 a-50 a-49 a-48 a-47 a-46 a-45 a-44 a-43 a-42 a-40 a-41 a-39 a-38 a-37 a-36 a-35 a-33 a-32 a-34 a-31 a-29 a-30 a-27 a-28 a-26 a-25 a-23 a-24 a-22 a-21 a-20 a-19 a-18 a-17 a-16 a-15 a-13 a-14 a-11 a-12 a-10 a-9 a-8 a-7 a-6 a-4 a-5 a-3 a-2 a-1

Overview

As run lengths and turnaround times morph, you need a cost-effective response to customer demands for even faster job turns, versioning and variable data, and just-in-time and on-demand printing while reducing inventory costs and waste. Now you can do it all with high-quality, high-speed digital LED printing up to 75 linear meters per minute on substrates up to 1.8 meters wide. Drive continuous operational, environmental, and competitive improvements into your business with the EFI Nozomi C18000.

Let us fuel the production of high-value applications and your operational efficiencies

  • Produce cost-effective on-demand and just-in-time jobs, fast-cycle proofs and prototypes, and customized campaigns with direct-to-substrate, production-level digital printing that reduces process steps, time, and costs
  • Produce high-quality, full-color graphics without the complexities of other printing processes
    • Increase profits by eliminating up-front make ready, plate costs, time, and storage
    • Eliminate ink mixing and storage, and the associated labor
  • Reduce labor costs and eliminate scrap waste in the litho lamination process by printing direct to substrate
  • Accommodate customer requests for versioned or variable jobs, last-minute edits, and changing buying decisions
  • Produce consistent color from proof to final print and from job to job, plus match brand colors accurately
  • Use the Fiery digital front end for efficient job management, get full visibility into your production and integrate with the EFI ecosystem and prepress workflows
  • Offer greener LED printing with low VOCs, and less waste and consumables
  • Inks meet OCC certification for recyclability and repulpability

Features

  • Single-pass, LED, digital drop-on-demand, piezo inkjet technology
  • Industrial, fixed array printheads
  • Four-level grayscale with resolution up to 360 x 720 dpi
  • CMYK, CMYK+W, CMYKOV, CMYKOV+W configurations available
  • Up to 75 linear m/min (246 linear ft/m); 7,224 m2/hr (77,758 ft2/hr); 1.8 m x 3 m sheet
  • One- and two-lane printing; two-lane printing supported when coupled with the top feeder to double the sheet throughput
  • Multi-image board printing supported in two-lane printing
  • In-line primer that allows dot gain and ink absorption control over a range of corrugated top sheets
  • Genuine EFI Inks
  • Fiery digital front end:
    • Advanced color management and extensive toolset for late-stage image editing
    • Exceptional print and color quality for complex, graphically-rich content
    • Accurate reproduction of brand colors plus color matching for consistent print results
    • Efficient job management with easy handling of short runs and versioned or variable data jobs
    • Full visibility into your production with accurate ink estimates and reporting of the actual ink used in print
    • Processing power to ensure the highest throughput
    • Integration with the EFI ecosystem and prepress workflows

Specifications

Productivity*
  • Up to 75 linear m/min (246 linear ft/m); 7,224 m2/hr (77,758 ft2/hr) (1.8 m x 3 m sheet)
  • Up to 6,600 sheets / hour (two-up printing, 0.8 m x 1 m sheets); 3,300 sheets / hour (one-up printing, 1.8 m x 1 m sheet)
Media/Handling
  • Board/sheet sizes (W x L) from 61 cm x 61 cm (24 in x 24 in) minimum to 1.8 m x 3.0 m (71 in x 118 in) maximum
  • Handles paper board thicknesses from 14-point cardstock and corrugated flutes: A, B, C, D, E, F, G, N, O, AB, AC, BC, EB, EF, and triple wall
  • Produce consistent color from proof to final print and from job to job, plus match brand colors accurately
  • Top and bottom feeding options for maximum flexibility
  • In-line active monitoring of print dynamics and image diagnostics of
  • 100% in-line, post print, quality inspection for image defects
  • Camera system for remote monitoring of complete printing process to optimize print quality in real-time
  • Tunable thresholds on quality inspection system permit rejection of failed sheets due to board or print defects
  • Automated material stacking to pallet or bundle
Genuine EFI Inks
  • LED inks supplied in a variety of volumes, including bulk containers
  • Available in cyan, magenta, yellow, black, orange, violet and white
  • Inks meet OCC-E certification for recyclability and re-pulp ability
Service and support
  • Cloud-based remote diagnostics and support to maximize up time
  • Optional wireless video broadcast system for continuous monitoring even when you’re not standing at the printer
Fiery NZ-1000
  • Fiery® high-performance bladed hardware
  • Unlimited Command WorkStation connections, up to 10 concurrent connections
  • Support for versioned, variable and VDP jobs
  • Color control through linearization, profiling and verification
  • Built-in PANTONE®, PANTONE® Plus, HKS®, HKS® 3000+, Toyo® and DIC® spot color libraries
  • Enabled to match industry standards such as ISO, G7, SWOP, GRACoL®
  • Integration with third party workflows, such as Esko Automation Engine and Kodak Prinergy
Environmental considerations
Configuration

Footprint

(L x W x H)

 Electrical Air
Four and six colour with bottom feeder, including cleaner, coater/dryer, and full stacker 121.4 ft x 33.5 ft x 16.5 ft
(37 m x 10.3 m x 5 m)		 350A at
380V or 280A at 480V supply		 Clean and dry air, 95 psi (6.5 bar);
nominal operating at 10.6 cf/min (300 L/min); peak at 113 cf/min (3,200 L/min)
Four and six colour with bottom feeder, including cleaner, coater/dryer, and full stacker 151 ft x 33.5 ft x 16.5 ft
(46 m x 10.3 m x 5 m)
